WP Series

Product Features:

Profile: aluminum
Stage: aluminum
Playground: aluminum

Article number

WP 69x30 WP 101x30 HWP 101x30 HWWP 101x45

Specifications

Vendor code: WP 69x30
Height from platform max: 2.60
Platform height: 0.50
Step width: 0.30
Platform length: 0.69
Weight: 4.3

Vendor code: WP 101x30
Height from platform max: 2.60
Platform height: 0.50
Step width: 0.30
Platform length: 1.01
Weight: 5.2

Vendor code: HWP 101x30
Height from platform max: 2.80
Platform height: 0.70
Step width: 0.30
Platform length: 1.01
Weight: 5.8

Vendor code: HWWP 101x45
Height from platform max: 2.80
Platform height: 0.70
Step width: 0.46
Platform length: 1.01
Weight: 7.6

Specifications

The passport

Вышки-подмости 2024 - 2027г.г.

Photo gallery

Technical specifications

Series WP

Vendor code	Height from platform max	Platform height	Step width	Platform length	Weight
WP 69x30	2.60	0.50	0.30	0.69	4.3
WP 101x30	2.60	0.50	0.30	1.01	5.2
HWP 101x30	2.80	0.70	0.30	1.01	5.8
HWWP 101x45	2.80	0.70	0.46	1.01	7.6
